Φ13.8-160K micro mesh Mesh fogging disc is a high-performance fogging disc, that is widely used in essential oils, aromatherapy, cosmetology, medical nebulization, and other fogging equipment.
The nebulizer disc is made of a corrosion-resistant 316L stainless steel diaphragm and high-performance piezoelectric sheet made of micro mesh (Mesh) material, which has durability, energy conversion, and a powerful nebulizing effect. The surface coating has antioxidant properties, which can effectively prevent the corrosion of the material due to acids and other chemical components in essential oils.
It is suitable for all kinds of atomizing equipment and can provide an efficient atomization effect according to different needs, quickly produce fine water mist or fragrance, and evenly diffuse into the air. Φ13.8 size makes it compatible with a variety of types of humidifiers and has low noise, stable atomization effect, and low power consumption.
| Model Number Size/Frequency/Model |
Diameter*Inner Diameter*Thickness | Electrical Parameter | Process Parameter | |||||||||||
| Stainless Steel Sheets304/316 | Piezoelectric Ceramics | Bump Specification | Resonant Frequency | Resonant Resistor | Electrostatic Capacitance | Usage Voltage |
Usage Power |
Aperture | Number OF Punched Holes ( about ) |
Perforated Area | Atomization Volume | Price Of Item | Categorization | |
| (mm) | (mm) | （KHz） | (Ω) | (pf)±20% | DC（V） | W | (µm) | (PCS) | Φ | (ml/min) | ＄ | |||
| 13.8-160KSDJ30P1.8 | 13.8-0.05 | Φ11.2*Φ5.2*0.6 | Cylindrical / Convex | 160K±10 | ＜300 | 1800 | 3.0-12V | 1.5±0.5 | 10 | 300 | 3.5 ± 0.5 | 2.5 | 1.5 | Fan Humidifying Beauty Misting Tablet |
With its high energy efficiency, low noise, and long service life, the stainless steel micro mesh fogging sheet effectively improves humidification efficiency and reduces water consumption at the same time by refining water molecules into tiny water mist. The use of micromesh fogging tablets also reduces pollution to the environment, as it does not require the use of chemical additives or heating to achieve the desired humidification effect. The performance of micromesh atomizing tablets is improving, making humidifiers more intelligent and user-friendly.
The company produces products mainly for high-quality customers to carry out, does not do low-end residual products, production according to the quality system requirements, and medical nebulizer tablets production process requirements for production and strict implementation. Regardless of which products in our company are strictly regulated production according to quality requirements. Each production channel is tested according to the testing standards so that customers are satisfied with the product. All materials are of high-quality selection, precision technology, refusing inferior residual.
